| Place of Origin: | Shandong, China |
| Brand Name: | luzhong machine |
| Certification: | CE ISO |
| Model Number: | QK1319 |
| Price: | $28,000.00/Sets >=1 Sets |
|---|---|
| Packaging Details: | Large spindle cnc lathe QK1319 Big hole pipe threading lathe<br>Type of package: Plywood case<br>Packaging size: CM(one set in one case)<br>N.W./G.W.: KGS |
| Supply Ability: | 20 Set/Sets per Month Large spindle cnc lathe QK1319 Big hole pipe threading lathe |
| Condition: | New | Type: | Horizontal |
|---|---|---|---|
| Max. Length Of Workpiece (mm): | 1000 Mm | Structure: | Flat Bed Lathe |
| Max. Spindle Speed (r.p.m): | 550 R.p.m | Machining Capacity: | Heavy Duty |
| Spindle Bore(mm): | 200 M'm | Width Of Bed (mm): | 550 Mm |
| Spindle Motor Power(kW): | 11 | No. Of Spindles: | Single |
| Number Of Axes: | 2 | Travel (X Axis)(mm): | 320 Mm |
| Travel (Z Axis)(mm): | 850 Mm | Positioning Accuracy (mm): | 5 Mm |
| Dimension(L*W*H): | 3300x1880x1850 | Voltage: | Customer's Requirement |
| Tool Post Stations: | 4 | Weight (KG): | 3400 |
| Warranty: | 1 Year, 12 Months | Applicable Industries: | Manufacturing Plant, Large Spindle Cnc Lathe QK1319 Big Hole Pipe Threa |
| Key Selling Points: | Automatic | Showroom Location: | India, UAE |
| Marketing Type: | New Product 2020 | Machinery Test Report: | Provided |
| Video Outgoing-inspection: | Provided | Warranty Of Core Components: | 1 Year |
| Core Components: | Bearing, Motor | CNC Or Not: | CNC |
| Automatic Grade: | Semi-automatic | After-sales Service Provided: | Engineers Available To Service Machinery Overseas, Online Support, Video Technical Support |
| Name: | Large Spindle Cnc Lathe QK1319 Big Hole Pipe Threading Lathe | Machine Type: | Large Spindle Cnc Lathe |
| Spindle Bore: | 200 | Function: | Cnc Lathes Machine |
| Spindle Speed: | 12 6 | Product Type: | Cnc Turning Machine |
| Max. Swing Diameter (mm): | 630 Mm | After Warranty Service: | Online Support |
| Local Service Location: | India, UAE | Port: | Any Port Of China Large Spindle Cnc Lathe QK1319 Big Hole Pipe Threading Lathe |
|
SPECIFICATION
|
Units
|
QK1313
|
QK1319
|
QK1319
|
|
|
|
|
Manual
|
Manual
|
HYD.
|
|
|
Swing over bed
|
mm
|
630/800
|
630/800
|
|
|
|
Swing over cross slide
|
mm
|
340/520
|
340/520
|
|
|
|
Distance between centers
|
mm
|
1000/1500/3000
|
1000/1500/3000
|
|
|
|
Pipe threading range
|
mm
|
30-126
|
50-193
|
|
|
|
Guideway width
|
mm
|
550
|
550
|
|
|
|
Max. load capacity
|
T
|
3
|
3
|
|
|
|
Spindle bore
|
mm
|
130
|
200
|
|
|
|
Spindle speed steps
|
-
|
VF. 3 steps
|
VF. 4 steps
|
HYD. 4 steps
|
|
|
Spindle speed range
|
rpm
|
30-720
|
20-550
|
|
|
|
Chuck
|
mm
|
φ400 3-jaw manual
|
φ500 3-jaw manual
|
|
|
|
Turret/tool post
|
-
|
CNC turret 4 position
|
CNC turret 4 position
|
|
|
|
Tool shank size
|
mm
|
32 x 32
|
32 x 32
|
|
|
|
X axis travel
|
mm
|
320/420
|
320/420
|
|
|
|
Z axis travel
|
mm
|
850/1350/2850
|
850/1350/2850
|
|
|
|
X axis rapid traverse
|
mm/min
|
4000
|
4000
|
|
|
|
Z axis rapid traverse
|
mm/min
|
6000
|
6000
|
|
|
|
Tailstock quill diameter
|
mm
|
φ100
|
φ100
|
|
|
|
Tailstock quill taper
|
-
|
MT5
|
MT5
|
|
|
|
Tailstock quill travel
|
mm
|
250
|
250
|
|
|
|
Main spindle motor
|
kW
|
11
|
11
|
|
|
|
Coolant pump motor
|
kW
|
0.125
|
0.125
|
|
|
|
Weight for 1000
|
kg
|
4500
|
4600
|
|
|
|
Weight for 1500
|
kg
|
5000
|
5100
|
|
|
|
Weight for 3000
|
kg
|
6000
|
6100
|
|
|
|
Dimension for 1000
|
mm
|
3300x1800x1850
|
3300x1880x1850
|
|
|
|
Dimension for 1500
|
mm
|
3800x1800x1850
|
3800x1880x1850
|
|
|
|
Dimension for 3000
|
mm
|
5300x1800x1850
|
5300x1880x1850
|
|
|
