CNC saw cutting machine GHS4260 Band sawing machine supplier

Name: CNC saw cutting machine GHS4260 Band sawing machine supplier
Brand: CNC saw cutting machine GHS4260 Band sawing machine supplier
SKU: CNC saw cutting machine GHS4260 Band sawing machine supplier
Price: 10 USD
Availability: InStock
Rating: 4.5 (179 reviews)

Product Details:

Certification:	CE.ISO

Payment & Shipping Terms:

Price:	$10,900.00/Sets >=1 Sets
Packaging Details:	CNC saw cutting machine GHS4260 Band sawing machine supplier<br>Type of package: Plywood case<br>Packaging size: 14672110 CM(one set in one case)<br>N.W./G.W.: 263 KGS
Supply Ability:	800 Roll/Rolls per Month CNC saw cutting machine GHS4260 Band sawing machine supplier

Contact Now

Detailed Product Description

Condition:	New	Machine Type:	Band Saw Machine
Video Outgoing-inspection:	Provided	Machinery Test Report:	Provided
Marketing Type:	New Product 2020	Warranty Of Core Components:	1 Year
Core Components:	Pump	Showroom Location:	India, UAE
Warranty:	1 Year	Weight (KG):	2500
Applicable Industries:	Machinery Repair Shops, Manufacturing Plant, CNC Saw Cutting Machine GHS4260 Band Sawing Machin	Key Selling Points:	Competitive Price
Product Name:	CNC Saw Cutting Machine GHS4260 Band Sawing Machine Supplier	Application:	Industrial Metal Cutting
Voltage:	Optional	Sawing Range:	600
Saw Blade Speed:	27\45\69 M/min	Main Motor:	5.5KW
Oil Pump Motor:	0.75kw	Cooling Pump Motor:	0.09kw
After-sales Service Provided:	Online Support	After Warranty Service:	Online Support
Local Service Location:	India, UAE	Port:	Any Port Of China CNC Saw Cutting Machine GHS4260 Band Sawing Machine Supplier

Feature :
extremely rigid dual-column cast-iron construction
PlC control for a fully automated sawing process
easy to use touch sreen monitor for easy and quick recording of saw parameters
The feed unit's linear measuring system ensure long term maximum accuracy
Feed of the saw frame is infinitely variable via a hydraulic throttle valve
extra rigid ,adjustable saw blade guide
hydraulic workpiece clamping with clamping pressure control and
bundle vise are included in the standard equipment
Standard equipment :
PlC control
1 saw blade belt
Hydraulic workpiece clamping
Bundle vise
Material support stand
Coolant system
Work lamp
Operation manual
Optional equipment:
automatic blade breakage control
Fast drop protection devise
Hydraulic blade tension
automatic chip removal device
Various blade linear speed
Blade protection covers
Wheel cover opening protection
Ce standard electrical equipment

Specifications			GHS4240	GHS4250	GHS4260
Sawing range	Round steel	Φ400mm	Φ500mm	Φ600mm
Sawing range		Square material	400×400mm	500×500mm	600×600mm
saw blade size			5000×41 ×1.3mm	5800×41 ×1.3mm	6500×41 ×1.3mm
Saw blade speed			27\45\69 m/min	27\45\69 m/min	27\45\69 m/min
Motor power	Main motor	4kw	5.5kw	5.5kw
		Oil pump motor	0.75kw	0.75kw	0.75kw
		Cooling pump motor	0.09kw	0.09kw	0.09kw
Sawing machine external form size			2400×1100 ×1900mm	2800×1400 ×1900mm	3200×1500 ×2000mm

Details Display

Recommend Products

Company Profile

FAQ

1:How can I choose the most suitable machines ?
A: Please tell me your specifications ,we can choose the best model for you , or you can choose the exact model .
You can also send us the products drawing ,we will choose the most suitable machines for you .

2: What's your main products of your company?
A: We specialized in all kinds of machines ,such as CNC Lathe Machine ,CNC Milling Machine ,Vertical Machining Center ,Lathe Machines ,Drilling Machine ,Radial Drilling Machine ,Sawing Machine ,Shaper machine and so on .

3: Where is our factory located? How can I visit there?
A : Our factory is located in Tengzhou City ,Shandong Province,277500 China. You are warmly welcomed to visit us.

4. What is your trade terms?
A : FOB, CFR and CIF all acceptable.

5: What's the Payment Terms ?
A : T/T ,30% initial payment when order ,70% balance payment before shipment ;
Irrevocable LC at sight .

5: What's the MOQ?
A: 1 set .(Only some low cost machines will be more than 1 set )
