| Place of Origin: | Shandong, China |
| Brand Name: | Luzhong Machine |
| Certification: | CE ISO |
| Model Number: | YQ32-200T |
| Price: | $9,400.00/Sets >=1 Sets |
|---|---|
| Packaging Details: | Plywood case <br>YQ32-200 Chinese Three Beams Four Column Hydraulic Press Machine |
| Supply Ability: | 100 Set/Sets per Day YQ32-200 Chinese Three Beams Four Column Hydraulic Press Machine |
| Machine Type: | Four-column Three-beam Hydraulic Press | Return Force (kN): | 400 KN |
|---|---|---|---|
| System: | Normal | Condition: | New |
| Voltage: | 380V/220V Optional | Dimension(L*W*H): | Machine Size |
| Weight (T): | 2.5 T | Motor Power (kw): | 7.5 Kw |
| Key Selling Points: | Competitive Price | Warranty: | 1 Year |
| Applicable Industries: | Manufacturing Plant | Showroom Location: | Indonesia, India, UAE |
| Marketing Type: | New Product 2020 | Machinery Test Report: | Provided |
| Video Outgoing-inspection: | Provided | Warranty Of Core Components: | 1 Year |
| Core Components: | Motor, Engine | Name: | YQ32 Series Chinese Three Beams Four Column Hydraulic Press Machine |
| CNC Or Not: | Normal | Power Source: | Mechanical |
| Power(W): | 5.5/7.5kw | Weight: | According To Specific Model |
| After Warranty Service: | Video Technical Support, Online Support, Spare Parts | Local Service Location: | Indonesia, India, UAE |
| Nominal Force (kN): | 2000 KN | Port: | Any Port In China |
Specifications | YQ32-200TA | YQ32-200TC |
Nominal pressure (KN) | 2000 | 2000 |
MAX.hydraulic pressure(Mpa) | 28 | 28 |
Oil cylinder range(mm) | 500 | 600 |
Max.opening(mm) | 900 | 1000 |
Hydraulic rod diameter | 300 | 300 |
Piston rod diameter | 280 | 280 |
Post diameter | 100 | 100 |
Table size(mm) | 800X800 | 1000X1000 |
Machine Height | 3000 | 3500 |
Down speed (mm/s) | 100 | 150 |
Pressing speed (mm/s) | 8-13.5 | 8-13.5 |
Return speed(mm/s) | 110 | 100 |
Oil pump | 40 | 40 |
motor power(kw) | 7.5 | 7.5 |
Return force(Kn) | 400 | 400 |
Ejecting stroke(mm) | 200 | 200 |
Weight | 4100 | 5400 |
