1.45 degrees slant bed CNC lathe 2.Higher accuracy Taiwan linear 3.Chip conveying capacity is large and convenient, customer could choose chip conveying in the front or in the back 4.Screw pre-stretching structure 5.Gang type tool post
 |
| Place of Origin: | Shandong, China |
| Brand Name: | Luzhong Machine Tool |
| Certification: | CE ISO |
| Model Number: | TCK6340S |
| Price: | $12,690.00/Sets >=1 Sets |
|---|---|
| Packaging Details: | The Package of cnc turning center is export standard plywood case with iron pallet below ,very strong and durable . <br>The Gang tool lathe cnc will be shipped to customers by land freight or sea freight . |
| Supply Ability: | 100 Set/Sets per Month |
| Condition: | New | Type: | TURNING CENTER |
|---|---|---|---|
| Max. Length Of Workpiece (mm): | 400 Mm | Max. Spindle Speed (r.p.m): | 4000 R.p.m |
| Machining Capacity: | Medium Duty | Spindle Bore(mm): | 56 M'm |
| Width Of Bed (mm): | 350 Mm | Spindle Motor Power(kW): | 5.5 |
| No. Of Spindles: | Single | Max. Turned Length (mm): | 400 |
| Number Of Axes: | 2 | Travel (X Axis)(mm): | 380 Mm |
| Travel (Z Axis)(mm): | 350 Mm | Positioning Accuracy (mm): | 0.005 |
| Repeatability (X/Y/Z) (mm): | 0.003 | Dimension(L*W*H): | 2300*1500*1750mm |
| Voltage: | 380V | CNC Control System: | GSK |
| Tool Post Stations: | 8, 6, 4 | Weight (KG): | 2500 |
| Warranty: | 1 Year | Applicable Industries: | Machinery Repair Shops, Manufacturing Plant, Factory |
| Key Selling Points: | Competitive Price | Showroom Location: | None |
| Marketing Type: | New Product 2020 | Machinery Test Report: | Provided |
| Video Outgoing-inspection: | Provided | Warranty Of Core Components: | 1 Year |
| Core Components: | Motor | Name: | CNC Slant Bed Lathe Gang Tool Lathe Cnc Turning Center |
| Max.swing Over Cross Slide: | 140mm | Max.processing Length: | 300mm / 410( Gang Tool) |
| Spindle Nose: | A2-5 | Spindle Bore: | 48mm |
| X/Z Rapid Traverse: | 18/18 M/min | Max.spindle Speed: | 4000rpm |
| Chuck Size: | 6/8in (10in) | X Axis Travel: | 400mm |
| Z Axis Travel: | 500mm | Max. Swing Diameter (mm): | 400 Mm |
| After-sales Service Provided: | Online Support, Video Technical Support | After Warranty Service: | Video Technical Support, Online Support |
| Local Service Location: | Indonesia, UAE | Port: | Qingdao Port |
Specification | Unit | SCK6340 | SCK6350 |
Max. swing over bed | mm | 400 | Φ520 |
Max. swing over cross slide | mm | 140 | Φ220 |
Max. processing length | mm | 300 | 410( gang tool)/530 (turret) |
X/Z axis travel | mm | 380/350 | 500/500 |
Spindle unit | mm | 170 | 200 |
Spindle nose | A2-5 | A2-6(A2-8 optional) | |
Spindle bore | mm | 56 | 66 |
Spindle drawing pipe diameter | mm | 45 | 55 |
Spindle speed | rpm | 3500 | 3000 |
Chuck size | inch | 6/8 | 10 |
Spindle motor | kw | 5.5 | 7.5/11 |
X/Z repeatability | mm | ±0.003 | ±0.003 |
X/Z axis feed motor torque | N.m | 6/6 | 7.5/7.5 |
X/Z rapid traverse | m/min | 18/18 | 18/18 |
Tool post type | Gang type tool post | Gang type tool post | |
Cutting tool shape size | mm | 20*20 | 25*25 |
Guide form | 45° inclined guide rail | 45° inclined guide rail | |
Total power capacity | kva | 9/11 | 14/18 |
Machine dimension (L*W*H) | mm | 2300*1500*1750 | 2550*1400*1710 |
N.W. | KG | 2500 | 2900 |
