| Place of Origin: | Shandong, China |
| Brand Name: | Luzhong Machine |
| Model Number: | TCK6340 TCK6350 |
| Price: | $14,350.00/Sets 1-9 Sets |
|---|---|
| Packaging Details: | The Package of our cnc lathe is export standard plywood case with iron pallet below ,very strong and durable . <br>The cnc lathe will be shipped to customers by land freight or sea freight . |
| Supply Ability: | 100 Set/Sets per Month High Precision TCK6336 Small Mini Slant Bed CNC lathe |
| Condition: | New | Type: | TURNING CENTER |
|---|---|---|---|
| Max. Length Of Workpiece (mm): | 410 Mm | Max. Spindle Speed (r.p.m): | 3500 R.p.m |
| Machining Capacity: | Light Duty | Spindle Bore(mm): | 48 Mm |
| Width Of Bed (mm): | 300 Mm | Spindle Motor Power(kW): | 5.5/7.5kw |
| No. Of Spindles: | Single | Number Of Axes: | 2 |
| Travel (X Axis)(mm): | 400 Mm | Travel (Z Axis)(mm): | 300 Mm |
| Positioning Accuracy (mm): | 0.01 Mm | Dimension(L*W*H): | 222*136*175 CM |
| Voltage: | 380V/220v | Tool Post Stations: | 4 |
| Weight (KG): | 2900 | Warranty: | 13 Months |
| Applicable Industries: | Manufacturing Plant | Key Selling Points: | Automatic |
| Showroom Location: | Russia, UAE | Marketing Type: | New Product 2020 |
| Machinery Test Report: | Provided | Video Outgoing-inspection: | Provided |
| Warranty Of Core Components: | 13 Months | Core Components: | Motor |
| Name: | High Precision TCK6340 Small Slant Bed Mini CNC Lathe | Max.swing Over Bed: | 390mm |
| Max.processing Length: | 200mm | Spindle Speed: | 4000rpm |
| X Travel: | 400mm | Z Travel: | 300mm |
| Spindle Nose: | A2-5 | Spindle Bore: | 48MM |
| Chuck Size: | 6/8 Inch | Power (kW): | 7.5 |
| Port: | Any Port In China |
Standard configuration | Optional configuration |
Servo main motor 140mm spindle units (3000 rpm) Taiwan linear Railway Ball screw Gang type Hydraulic collet | Taiwan spindle units Taiwan ball screw 6/8 Electric turret 8/12 Hydraulic turret Hydraulic chuck Chip conveyor |
SPECIFICATIONS | Units | TCK6340 | TCK6340S | TCK6350 |
Swing over bed | mm | 400 | 400 | 500 |
Swing over cross slide | mm | 140 | 140 | 220 |
Distance between centers | mm | 200 | 500 | 410 |
Spindle bore | mm | 48 | 56 | 66 |
Spindle nose type | - | A2-5 | A2-5 | A2-6 |
Spindle speed steps | - | Stepless | Stepless | Stepless |
Spindle speed range | rpm | 3500 | 3500 | 3000 |
Turret/tool post | - | Gang type | Gang type | Gang type |
Tool size | mm | 20 x 20 | 20x 20 | 25 x 25 |
X axis travel | mm | 400 | 400 | 500 |
Z axis travel | mm | 300 | 500 | 410 |
X axis rapid traverse | mm/min | 18000 | 18000 | 18000 |
Z axis rapid traverse | mm/min | 18000 | 18000 | 18000 |
Main spindle motor | kw | 5.5 | 5.5 | 7.5 |
Guide rail type | - | Linear rail | Linear rail | Linear rail |
Machine weight | kg | 2300 | 2500 | 2900 |
Overall dimension | mm | 2200x1600x1780 | 2400x1600x1780 | 2500x1600x1890 |
