live tooling cnc lathe machine TCK6350 Machining cnc lathe

Product Details:

Place of Origin:	Shandong, China
Brand Name:	Luzhong Machine
Certification:	CE ISO

Payment & Shipping Terms:

Price:	$15,500.00/Sets >=1 Sets
Packaging Details:	live tooling cnc lathe machine TCK6350 Machining cnc lathe<br>Type of package: Plywood case<br>Packaging size:255014001710 CM(one set in one case)<br>N.W./G.W.: 2900 KGS
Supply Ability:	20 Set/Sets per Month live tooling cnc lathe machine TCK6350 Machining cnc lathe

Contact Now

Detailed Product Description

Condition:	New	Type:	TURNING CENTER
Max. Length Of Workpiece (mm):	410 Mm	Max. Spindle Speed (r.p.m):	3000 R.p.m
Machining Capacity:	Medium Duty	Spindle Bore(mm):	48 M'm
Width Of Bed (mm):	400 Mm	Spindle Motor Power(kW):	7.5
No. Of Spindles:	Single	Number Of Axes:	2
Travel (X Axis)(mm):	400 Mm	Travel (Z Axis)(mm):	300 Mm
Positioning Accuracy (mm):	5 Mm	Dimension(LWH):	255014001710
Voltage:	Customer's Requirement	Tool Post Stations:	4
Weight (KG):	2900	Warranty:	1 Year, 12 Months
Applicable Industries:	Manufacturing Plant	Key Selling Points:	Automatic
Showroom Location:	UAE	Marketing Type:	New Product 2020
Machinery Test Report:	Provided	Video Outgoing-inspection:	Provided
Warranty Of Core Components:	1 Year	Core Components:	Bearing, Motor
CNC Or Not:	CNC	Automatic Grade:	Automatic
After-sales Service Provided:	Engineers Available To Service Machinery Overseas, Online Support, Video Technical Support	Name:	Live Tooling Cnc Lathe Machine TCK6350 Machining Cnc Lathe
Machine Type:	Cnc Lathe Machine Specification	Spindle Bore:	66
Spindle Speed:	3000	Color:	Optional
Function:	Price Cnc Lathe	Max. Swing Diameter (mm):	520 Mm
After Warranty Service:	Online Support	Local Service Location:	UAE
Port:	Any Port Of China Live Tooling Cnc Lathe Machine TCK6350 Machining Cnc Lathe

SPECIFICATIONS	Units	TCK6340	TCK6340S	TCK6350
Swing over bed	mm	400	400	500
Swing over cross slide	mm	140	140	220
Distance between centers	mm	300	500	410
Spindle bore	mm	48	56	66
Spindle nose type	-	A2-5	A2-5	A2-6
Spindle speed steps	-	Stepless	Stepless	Stepless
Spindle speed range	rpm	3500	3500	3000
Turret/tool post	-	Gang type	Gang type	Gang type
Tool size	mm	20 x 20	20x 20	25 x 25
X axis travel	mm	400	400	500
Z axis travel	mm	300	500	410
X axis rapid traverse	mm/min	18000	18000	18000
Z axis rapid traverse	mm/min	18000	18000	18000
Main spindle motor	kw	5.5	5.5	7.5
Guide rail type	-	Linear rail	Linear rail	Linear rail
Machine weight	kg	2300	2500	2900
Overall dimension	mm	2200x1600x1780	2400x1600x1780	2500x1600x1890

Details Display

Recommend Products

Company Profile

FAQ

1:How can I choose the most suitable machines ?
A: Please tell me your specifications ,we can choose the best model for you , or you can choose the exact model .
You can also send us the products drawing ,we will choose the most suitable machines for you .

2: What's your main products of your company?
A: We specialized in all kinds of machines ,such as CNC Lathe Machine ,CNC Milling Machine ,Vertical Machining Center ,Lathe Machines ,Drilling Machine ,Radial Drilling Machine ,Sawing Machine ,Shaper machine and so on .

3: Where is our factory located? How can I visit there?
A : Our factory is located in Tengzhou City ,Shandong Province,277500 China. You are warmly welcomed to visit us.

4. What is your trade terms?
A : FOB, CFR and CIF all acceptable.

5: What's the Payment Terms ?
A : T/T ,30% initial payment when order ,70% balance payment before shipment ;
Irrevocable LC at sight .

5: What's the MOQ?
A: 1 set .(Only some low cost machines will be more than 1 set )
